Spesifikasi Lengkap :
13.1 megapixel DX-format CMOS sensor (piksel efektif: 12,3 juta)
720p HD video
3.0 "LCD monitor (920.000 titik)
Gambar pembersih sensor (sensor shake)
AF 51 poin (dengan pelacakan 3D)
200-3200 IS0 rentang (6400 diperluas)
7 frame per detik continuous shooting (buffer: 17 RAW, 44 JPEG fine, 100 JPEG Normal)
EXPEED image processing
Kontrol gambar - gambar parameter konsisten dengan semua DSLR Nikon saat ini
Sama EN-EL3e baterai sebagai D300
72 thumbnail tampilan di pemutaran
14-bit A / D konversi
Super cepat operasi (power-up 13 ms, shutter lag 45 ms, black-out 100 ms)
Shutter kehidupan 150.000 eksposur
Multi-CAM3500DX Auto Focus sensor (51-point, 15 cross-type, cakupan lebih vertikal)
Auto-fokus pelacakan dengan warna (menggunakan informasi dari sensor AE 1005-pixel)
Auto-fokus kalibrasi (fine-tuning) (tubuh tetap atau sampai dengan 20 pengaturan lensa terpisah) sekarang tersedia
Scene Recognition System (menggunakan AE sensor, AF sensor)
Picture Control image parameter preset (ganti Color Mode I, II dan III)
Custom parameter gambar sekarang mendukung terang serta kontras
Compact Flash UDMA support
Live View dengan fase baik mendeteksi (cermin atas / bawah) atau kontras mendeteksi Auto Focus
HDMI HD video output
'Active D-Lighting' (menyesuaikan pengukuran serta menerapkan kurva D-Lighting)
Detailed 'Control Panel' jenis tampilan di monitor LCD, perubahan warna dalam kegelapan
Baru MB-D10 grip vertikal sepenuhnya terintegrasi ke dalam tubuh, multi jenis baterai yang kompatibel
Tombol disegel terhadap kelembaban
Warna Patch
Tech Specs
*
Image Sensor Format
FX
*
Image Sensor Type
CMOS
*
Sensor Size
36.0 x 23.9mm
*
Total Pixels
12.87 million
*
Effective Pixels
12.1 million
*
Image Area (pixels)
FX-format
(L) 4,256 x 2,832
(M) 3,184 x 2,120
(S) 2,128 x 1,416
DX-format
(L) 2,784 x 1,848
(M) 2,080 x 1,384
(S) 1,392 x 920
*
Top Continuous Shooting Speed at full resolution
5 frames per second
*
Continuous Shooting Options
FX-format
CH: Up to 5 frames per second
CL: Up to 4 frames per second
DX-format
CH: Up to 5 frames per second
CL: Up to 4 frames per second
*
LCD Monitor Size
3 in. diagonal
*
LCD Monitor Type
Wide Viewing Angle TFT-LCD
Super Density
*
LCD Monitor Resolution
920,000 Dots
*
LCD Monitor Angle of View
170-degree wide-viewing angle
*
LCD Monitor Adjustments
Brightness, 7 levels
*
Slowest Shutter Speed
30 sec.
*
Fastest Shutter Speed
1/8000 sec.
*
Bulb Shutter Setting
Yes
*
Mirror Lock Up
Yes
*
Lowest Standard ISO Sensitivity
200 in steps of 1/3, 1/2, 1 EV
*
Highest Standard ISO Sensitivity
6400 in steps of 1/3, 1/2, 1 EV
*
Highest Expanded ISO Sensitvity
Hi-2 (ISO 25,600 equivalent)
*
Expanded ISO Sensitivity Options
o Lo-1 (ISO 100 equivalent), in steps of 1/3, 1/2, 1 EV
o Hi-1 (ISO-12,800 equivalent), in 1/3, 1/2 or 1 EV steps
o Hi-2 (ISO-25,600 equivalent), 1 EV step
*
Storage Media
CompactFlash© (Type I/II, compliant with UDMA)
MicroDrive©
*
Storage System
Uncompressed 12/14-bit NEF (RAW)
Uncompressed 12-bit NEF (RAW)
Compressed 12/14-bit NEF (RAW, Lossless compressed): approx. 60-80 percent
Compressed 12/14-bit NEF (RAW, Compressed): approx. 45-60 percent
JPEG: JPEG-baseline-compliant; can be selected from Size priority and Optimal Quality
TIFF (RGB)
*
File System
Compliant with DCF 2.0
DPOF
EXIF 2.21
*
Exposure Modes
Programmed Auto (P) with Flexible Program
Shutter- Priority Auto (S)
Aperture-Priority Auto (A)
Manual (M)
*
Exposure Metering System
1,005-pixel RGB sensor 3D Color Matrix Metering II
*
Metering Range
1. 0 to 20 EV (Matrix or Center-weighted metering);
2. 2 to 20 EV (Spot metering) (ISO 100 equivalent, f/1.4 lens, at 20 degrees C/68 degrees F)
*
Exposure Meter Coupling
CPU
AI
*
Exposure Compensation
±5 EV in increments of 1/3, 1/2, 1 EVEV in increments of 1/3, 1/2, 1
*
Exposure Lock
Yes
*
Exposure Bracketing
Yes
From 2 to 9 exposures in increments of 1/3, 1/2, 2/3 or 1 EV
*
Shutter Release Modes
LiveView [LV] mode
Continuous low-speed [CL] mode; 1-4 frames per second Continuous high-speed [CH] mode; 5 frames per second
*
White Balance
Sun
Shade
Fluorescent
Incandescent
Flash
Preset
Fine Tune by Kelvin Color Temperature Setting
Auto
*
White Balance Bracketing
Yes, 2 to 9 exposures, in increments of 1, 2 or 3
*
LiveView Shooting
Handheld mode
Tripod mode
*
Playback Functions
Full frame
Zoom
Slideshow
Histogram
Highlight point display
Auto image rotation
Thumbnail (4 or 9 segments)
*
Interface
Hi-speed USB
NTSC
PAL
HDMI
10-pin Terminal
*
Lens Mount
Nikon F mount
*
Compatible Lenses
1) Type G or D AF NIKKOR: All functions supported
2) DX AF NIKKOR: All functions supported except FX-format (36×24)/image size
3) AF NIKKOR other than type G or D*2: All functions supported except 3D Color Matrix Metering II
4) AI-P NIKKOR: All functions supported except auto-focus and 3D Color Matrix Metering II
5) Non-CPU AI NIKKOR: Can be used in exposure modes A and M; electronic rangefinder can be used if maximum aperture is f/5.6 or faster; Color Matrix Metering and aperture value display supported if user provides lens data
*
Picture Angle
Equivalent to angle produced by lens focal length (1.5 times when DX format is selected)
*
Viewfinder
SLR-type with fixed eye-level pentaprism
*
Viewfinder Frame Coverage
Approx. 95%
*
Viewfinder Diopter Adjustment
-3 to +1m-1
*
Viewfinder Eyepoint
18mm
*
Reflex Mirror
Quick-return type
*
Interchangeable Focusing Screens
No
Type B BriteView Clear Matte VI screen with superimposed AF points
*
Viewfinder Magnification
Approx. 0.72x (50mm f/1.4 lens at infinity)
*
Lens Aperture
Instant-return type with depth-of-field preview button
*
Depth-of-field Control
Yes
*
Autofocus System
Autofocus TTL phase detection, 51 focus points
(15 cross-type sensors) by Nikon Multi-CAM 3500FX autofocus module; Detection: -1 to +19 EV (ISO 100 at 20°C/68°F); AF fine adjustment possible. AF-assist illuminator (range approx. 1.6-9.8 ft./0.5-3.0m)
*
Maximum Autofocus Areas/Points
51
*
Autofocus Fine Tune
Yes
Records values for up to 12 user selected lenses
*
Focus Modes
Single-servo AF (S)
Continuous-servo (C)
Manual
Auto
Manual (M) with electronic rangefinder
*
Single-point AF Mode
Yes
*
Dynamic AF Mode
Yes
Number of AF points: 9, 21, 51 and 51 with 3D-tracking
*
Auto-area AF Mode
Yes
*
Focus Lock
AE-L/AF-L button
Half press of shutter-release button (single-point AF in AF-S)
*
Picture Control
Standard
Neutral
Vivid
Monochrome
Nine User-customizable settings
*
In-Camera Image Editing
Trim
D-Lighting
Color Balance
Image Overlay
Filter Effects
Monochrome
Red-eye correction
*
Built-in Flash
Yes
Manual pop-up type
*
External Flash Shoe
Yes
*
External Flash Shoe Type
Standard ISO 518 hot-shoe contact with safety lock
*
Dust-Off Reference Photo
Yes
*
Virtual Horizon Camera Indicator
Yes
Also visible in LiveView Modes
*
Save/Load Camera settings
Yes
*
Nikon Creative Lighting System Compatibility
Yes
Built-in Commander Mode 2 Groups: A and B
*
Flash Sync Speed
up to 1/250
*
X-Sync Speed
up to 1/250
*
FP High Speed Sync
up to 1/8000
*
Flash Sync Modes
Front-curtain sync (normal)
Slow sync
Rear-curtain sync
Red-eye reduction
Red-eye reduction with slow sync
*
Flash Control
1) TTL flash control with 1,005-pixel RGB sensor; i-TTL balanced fill-flash and standard i-TTL fill-flash available with SB-900, SB-800, SB-600 or SB-400
2) Auto aperture (AA): Available with SB-900, SB-800 and CPU lens
3) Non-TTL auto (A): Available with SB-900, SB-800, 28, 27 or 22s
4) Range-priority manual (GN): Available with SB-900, SB-800
*
Flash Sync Terminal
Yes
*
Accessory Shoe
Yes
*
Self-timer
Electronically controlled timer with duration of 2, 5, 10 or 20 sec.
*
World Time Setting
Yes
*
Date, Time and Daylight Savings Time Settings
Yes
*
Battery Type
Rechargeable
*
Battery / Batteries
EN-EL3e Lithium-ion Battery
*
AC Adaptor
EH-5a AC Adapter
*
Battery Charger
MH-18a Quick Charger
*
Image Comment
Yes
*
Voice Memo Function
No
*
Battery Life (shots per charge)
1000 shots (CIPA)
*
Tripod Socket
¼-20
*
Approx. Dimensions
Width 5.8 in. (147mm)
Height 4.8 in. (123mm)
Depth 3.0 in. (77mm)
*
Approx. Weight
35 oz. (995g)
*
Supported Languages
Chinese (Simplified and Traditional), Dutch, English, Finnish, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Swedish
*
Optional Accessories
MB-D10 Mulit-power Battery Pack, WT-4a Wireless Transmitter, DK-17M Magnifying Eyepiece, EH-5a AC Adapter, Capture NX 2 Software, Camera Control Pro 2 Software, Image Authentication Software
*
Supplied Accessories
EN-EL3e Rechargeable Li-ion Battery, MH-18a Quick Charger, UC-E4 USB Cable, EG-D100 Video Cable, AN-D700 Camera Strap, BF-1A Body Cap, BS-1 Accessory Shoe Cover, BM-9 LCD Monitor Cover, Software Suite CD-ROM
